Type

Flatbed Scanner

Scanning element

CIS

Light source

3-color (RGB) LED

Optical resolution

2400 x 2400dpi1

Selectable resolution

25 - 19200dpi2

Interface

USB2.0 High-Speed Mini-B

Scanning gradation (colour)

48 bit input -> 48/24 bit output

Scanning gradation (greyscale)

16 bit input -> 8 bit output

Maximum Document Size

A4 / Letter (216 x 297mm)

EZ-Scan Buttons

4 buttons (PDF, AUTOSCAN, COPY, SEND)

Scanning speed

(colour)
(Reflective)
14.8msec/line (2400 dpi)
6.6msec/line (1200 dpi)
3.8msec/line (600 dpi)
2.2msec/line (300 dpi)3

(greyscale, B&W)
(Reflective）
4.3msec/line (2400 dpi)
2.2msec/line (1200 dpi)
1.3msec/line (600 dpi)
2.2msec/line (300 dpi)4

Scan speed (A4, 300dpi, Colour)

Approx. 10 sec5

Scan speed (4x6", 300dpi, Colour)

Approx. 5 sec6

Preview Speed

Approx. 9 sec7

Software Included

Scan Gear for Win
Scan Utility for Win

Power Supply

Supplied via USB port

Power Consumption

approx. 4.5W (in operation, maximum)
approx. 0.3W (standby)

Dimensions

250×367×42 mm

Weight

1.7kg

Operating Temperature range

5 - 35 °C

Operating Humidity Range

10 - 90 %RH, without condensation formation

Supported Operating Systems

Windows 10、Windows 8.1、Windows 7 SP189
Operation can only be guaranteed on a PC with pre-installed Windows 7 or later.
OS X 10.11.6、macOS 10.12〜macOS 10.13

Minimum System Requirements

Display: 1024 x 768 XGA

Standard disclaimers

All Specifications subject to change without notice.

All brand and product names are trademarks of their respective companies.

* Windows only
